Nissan Marine 4 Stroke NSF5C1

Nissan Marine 4 Stroke NSF5C1

$1,614.19

Tohatsu Nissan Genuine OEM Outboard Motor Part Number Nissan Marine 4 Stroke NSF5C1
Sold Out

All parts are sold individually.
The listed price is for one item.
NSF5C1
Click on Image to view larger image
Outboard Motor Information
Manufactured by Nissan Marine
Model No. NSF5C1
HP 5 HP
Shaft Size 15" Short Shaft
MSRP Price $1,754.55
Sales Price $1,614.19
Your Saving $140.36
Shipping Free
Sales Tax1 $0.00
USA Delivery Time2 1-6 Days
Worldwide Delivery Time3 No Shipping4
Availability Out of Stock

1 Florida residents pay Florida Sales Tax
2 When the item leaves the warehouse
3 For Sale in the USA only.
4 We do not ship outboards Worldwide.

Outboard Motor Specifications

Nissan Marine NSF5C1 1 15" Short Shaft View Download
Engine (No. of Cylinder) 1
Output 5 hp (3.7 kw)
Displacement 123 cc (7.5 cu.in)
Bore x Stroke 59 x 45 mm (2.32 x 1.77 in)
Starting Manual
Control Type Tiller Handle
Gear Shift Forward - Neutral - Reverse
Gear Ratio 2.15:1
Propeller Selection Range 6" - 9"
Transom Height 15", 20"
Fuel Unleaded Gasoline (87 Octane)
Oil Type NMMA Certified FC-W® 4-stroke oil**
SAE 10W-30/40 (SF, SG, SH, SJ)
Oil Capacity 15 fl. oz. (450 mL)
Fuel Tank 3.1 US Gal. (12 Lit) Separate Fuel Tank
Weight* 55 lbs (25 kg)
Alternator Output Optional: 12V, 60W, 5A
Max. RPM Range 4,500 - 5,500
Digital CD Ignition System S
Start In Gear Protection S
Thermostat Controlled Cooling System S
Through-The-Prop Exhaust S
Shallow Water Drive S
Oil Pressure Warning S

LEGEND:
S......Standard Features
O......Optional on Certain Models

* Weight specification is based on the lightest version.
** FC-W® is a registered trademark of the National Marine Manufacturers Assoc. (NMMA)
Specifications and descriptions are subject to change without notice.



Features

Front Mounted Shift Lever

The new front mounted shift lever, an industry first in its class, allows for better drivability.




Longer Tiller Handle
 The tiller handle has been extended 110mm from previous models for easier access and maneuverability.
Larger Carrying Handle and newly designed Holding Grip on bottom cowl

A newly installed holding grip on the bottom of the cowl as well as a larger carrying handle makes transporting this compact model even easier.
Propeller Hub Exhaust
Through-the-prop exhaust helps reduce engine noise.




  • Light and compact!
  • Front mounted shift lever, an industry first in its class!
  • Designed with proven technology
  • Greatly reduced vibration for smooth and stable running at all speeds
  • Greatly reduced induction noise for a quieter ride
  • Ultra Low emission, EPA and CARB approved
  • 5 Year limited warranty

  • Digital CD ignition for easier engine starting, quicker throttle response and smoother trolling
  • Recoil starter with larger reel making manual starting fast and easy
  • Shallow water drive
  • 6 trim positions
  • Adjustable steering friction for reducing steering effort
  • New longer tiller handle (110mm extension)
  • Newly designed holding grip and larger carrying handle

  • Through-the-prop exhaust for a quieter ride
  • Thermostatically controlled cooling system for consistent engine temperature
  • Stainless steel water pump housing liner for outstanding durability
  • High grade marine aluminum alloy that provides the ultimate protection against corrosion
  • Zinc coating on internal water passages for superior corrosion resistance
  • Plastic fuel tank with fuel gauge on the cap
  • Aluminum propeller

  • Low oil pressure indicator
  • Safety lanyard (an essential protection feature standard on all Nissan outboards)
  • Start-in-gear protection for safer engine starting
  • Over-rev. limiter
